The proper way to serialize and deserialize DateTimeOffset in XML is to use the DataContractSerializer instead of the standard XmlSerializer.  The reason is that the XMLSerializer does not support certain aspects of the DateTimeOffset structure (don’t ask me what they are, but that’s what Microsoft states is their reasoning for not supporting it).  I tend to try and code using generics whenever possible, especially when it’s stuff like this.

Thus, here’s an example of how to serialize any class using it (I’m using UTF8 encoding here, but you can use whatever you like):

     public static string SerializeObject<T>(T instance) where T : class
     {
       try
       {
         MemoryStream stream = new MemoryStream();
         DataContractSerializer serializer = new DataContractSerializer(typeof(T));
         serializer.WriteObject(stream, instance);
         return new UTF8Encoding().GetString(stream.ToArray());
       }
       catch(Exception ex)
       {
         ...
       }
     }

And here’s how to deserialize it again:

     public static T DeserializeObject<T>(string data) where T : class
     {
       try
       {
         MemoryStream memoryStream = new MemoryStream(new UTF8Encoding().GetBytes(data));
         DataContractSerializer serializer = new DataContractSerializer(typeof(T));
         return (T)serializer.ReadObject(memoryStream);
       }
       catch
       {
         ...
       }
     }

There are still modules out there using the old setting style for connection strings:

 <appSettings>
   <add key="SiteSqlServer" value="Server=(local);Database=DNN;Integrated Security=True" />
 </appSettings>

I spent the better part of a day and a half trying to diagnose why all the modules from one particular 3rd party vendor wouldn’t work on my box… lesson learned.

So it’s been a while since I posted last, but recently I had the opportunity to do some serious XAML binding stuff, which I thought I’d share with you. If you’ve ever wanted an easy way to create an editable gridview inside a listview, it can seem like a pretty daunting task, but actually, it’s really not that tough. You can setup a binding scenario that will do 80% of the work for you. Try the following out for size: First, the XAML code:

 <Window x:Class="EditableGridViewExample.Window1"
     xmlns:local="clr-namespace:EditableGridViewExample"
     xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
     xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
     Title="Window1">
  <Window.Resources>
   <local:BoolToVisibilityConverter x:Key="b2v" />
   <Style TargetType="{x:Type TextBlock}" x:Key="TextBlockStyle">
    <Setter Property="Visibility">
     <Setter.Value>
      <MultiBinding Converter="{StaticResource b2v}" ConverterParameter="False" >
       <Binding ElementName="EditModeCheckBox" Path="IsChecked" />
       <Binding RelativeSource="{RelativeSource FindAncestor, AncestorType={x:Type ListViewItem}}" Path="IsSelected" />
      </MultiBinding>
     </Setter.Value>
    </Setter>
    <Setter Property="VerticalAlignment" Value="Center" />
   </Style>
   <Style TargetType="{x:Type TextBox}" x:Key="TextBoxStyle">
    <Setter Property="Visibility">
     <Setter.Value>
      <MultiBinding Converter="{StaticResource b2v}" ConverterParameter="True" >
       <Binding ElementName="EditModeCheckBox" Path="IsChecked" />
       <Binding RelativeSource="{RelativeSource FindAncestor, AncestorType={x:Type ListViewItem}}" Path="IsSelected" />
      </MultiBinding>
     </Setter.Value>
    </Setter>
    <Setter Property="VerticalAlignment" Value="Center" />
   </Style>
  </Window.Resources>
  <Grid>
   <Grid.RowDefinitions>
    <RowDefinition Height="Auto" />
    <RowDefinition Height="*" />
   </Grid.RowDefinitions>
   <CheckBox x:Name="EditModeCheckBox" Content="Edit Mode" />
   <ListView Grid.Row="1" x:Name="WindowListView" ItemsSource="{Binding}">
    <ListView.View>
     <GridView>
      <GridViewColumn>
       <GridViewColumnHeader Tag="ColumnA" Content="Object" />
       <GridViewColumn.CellTemplate>
        <DataTemplate>
         <Grid>
          <TextBlock Text="{Binding Path=ColumnA}" Style="{StaticResource TextBlockStyle}" />
          <TextBox Text="{Binding Path=ColumnA}" Style="{StaticResource TextBoxStyle}" />
         </Grid>
        </DataTemplate>
       </GridViewColumn.CellTemplate>
      </GridViewColumn>
      <GridViewColumn>
       <GridViewColumnHeader Tag="ColumnB" Content="Type" />
       <GridViewColumn.CellTemplate>
        <DataTemplate>
         <Grid>
          <TextBlock Text="{Binding Path=ColumnB}" Style="{StaticResource TextBlockStyle}"/>
          <TextBox Text="{Binding Path=ColumnB}" Style="{StaticResource TextBoxStyle}" />
         </Grid>
        </DataTemplate>
       </GridViewColumn.CellTemplate>
      </GridViewColumn>
     </GridView>
    </ListView.View>
   </ListView>
  </Grid>
 </Window>

Now, the codebehind (I put everything in one file to make it easy to use):

 using System;
 using System.Collections.ObjectModel;
 using System.Windows;
 using System.Windows.Data;

 namespace EditableGridViewExample
 {
  public class ListItems : ObservableCollection<ListData>
  {
   /// <summary>
   /// Initializes a new instance of the <see cref="ListItems"/> class.
   /// </summary>
   public ListItems()
   {
    this.Add(new ListData() { ColumnA = "apple", ColumnB = "fruit" });
    this.Add(new ListData() { ColumnA = "jaguar", ColumnB = "animal" });
    this.Add(new ListData() { ColumnA = "lullaby", ColumnB = "music" });
    this.Add(new ListData() { ColumnA = "monkey", ColumnB = "animal" });
    this.Add(new ListData() { ColumnA = "orange", ColumnB = "fruit" });
    this.Add(new ListData() { ColumnA = "whale", ColumnB = "mammal" });
    this.Add(new ListData() { ColumnA = "coathanger", ColumnB = "other" });
   }
  }

  public class BoolToVisibilityConverter : IMultiValueConverter
  {
   /// <summary>
   /// Converts source values to a value for the binding target. The data binding engine calls this method when it propagates the values from source bindings to the binding target.
   /// </summary>
   /// <param name="values">The array of values that the source bindings in the <see cref="T:System.Windows.Data.MultiBinding"/> produces. The value <see cref="F:System.Windows.DependencyProperty.UnsetValue"/> indicates that the source binding has no value to provide for conversion.</param>
   /// <param name="targetType">The type of the binding target property.</param>
   /// <param name="parameter">The converter parameter to use.</param>
   /// <param name="culture">The culture to use in the converter.</param>
   /// <returns>
   /// A converted value.If the method returns null, the valid null value is used.A return value of <see cref="T:System.Windows.DependencyProperty"/>.<see cref="F:System.Windows.DependencyProperty.UnsetValue"/> indicates that the converter did not produce a value, and that the binding will use the <see cref="P:System.Windows.Data.BindingBase.FallbackValue"/> if it is available, or else will use the default value.A return value of <see cref="T:System.Windows.Data.Binding"/>.<see cref="F:System.Windows.Data.Binding.DoNothing"/> indicates that the binding does not transfer the value or use the <see cref="P:System.Windows.Data.BindingBase.FallbackValue"/> or the default value.
   /// </returns>
   public object Convert(object[] values, Type targetType, object parameter, System.Globalization.CultureInfo culture)
   {
    bool param = bool.Parse(parameter as string);
    bool combined = true;
    foreach (bool val in values) combined &= val;
    return combined == param ? Visibility.Visible : Visibility.Hidden;
   }

   public object[] ConvertBack(object value, Type[] targetTypes, object parameter, System.Globalization.CultureInfo culture)
   {
    throw new NotImplementedException();
   }
  }

  public class ListData : DependencyObject
  {
   public static readonly DependencyProperty ColumnAProperty =
    DependencyProperty.Register("ColumnAProperty", typeof(string),
    typeof(ListData), new UIPropertyMetadata(null));

   public static readonly DependencyProperty ColumnBProperty =
    DependencyProperty.Register("ColumnBProperty", typeof(string),
    typeof(ListData), new UIPropertyMetadata(null));

   /// <summary>
   /// Gets or sets the column A.
   /// </summary>
   /// <value>
   /// The column A.
   /// </value>
   public string ColumnA
   {
    get { return (string)GetValue(ColumnAProperty); }
    set { SetValue(ColumnAProperty, value); }
   }

   /// <summary>
   /// Gets or sets the column B.
   /// </summary>
   /// <value>
   /// The column B.
   /// </value>
   public string ColumnB
   {
    get { return (string)GetValue(ColumnBProperty); }
    set { SetValue(ColumnBProperty, value); }
   }
  }

  public partial class Window1 : Window
  {
   /// <summary>
   /// Initializes a new instance of the <see cref="MainWindow"/> class.
   /// </summary>
   public Window1()
   {
    InitializeComponent();

    // bind datacontext of the list view to a new listitems observable collection
    this.WindowListView.DataContext = new ListItems();
   }
  }
 }


Oh, and if you’re wondering how I got it to format so nicely, I’m using this the following blogspot source code formatting tool.

I live in the Western Communities on Vancouver Island, in British Columbia. I recently heard this story and I think it’s a great argument why public services like search and rescue should charge for rescues if the person(s) being rescued break the law:

The story starts with a plane crash landing on the beach at the Carmanah Point Lighthouse back in February. The pilot and one passenger, were flying his little plane (apparently something he built himself from a hobbyist kit) when they crash landed on the beach. After climbing to the lighthouse to seek help, the Canadian Armed Forces sent out a helicopter which picked them up and took them to Victoria.

Two days later, the pilot, along with his two brothers, headed back to the plane. Apparently they planned to repair the plane and fly it out before the wind and ocean tides tore it apart. The trek was roughly 16km and the terrain made it extremely difficult to navigate. The three lugged in their tools, a gun for protection (from bears and cougars I imagine), and a replacement propeller.

You ready for this? Guess what, they got lost. When they didn’t show up at the lighthouse, they were reported missing and a search began. They eventually made it to the lighthouse, but were not allowed to fly the plane out. The coast guard flew them out by helicopter the next day.

The crown has charged the pilot with unlawfully landing an aircraft in a park and for firearms possession. Additionally, both he and his two brothers, are also charged with trespassing in a closed area.

Uh, hold on a minute, why don’t they make them pay the cost of BOTH rescues? It costs the taxpayers money.

As a footnote, from what I understand, the pilot did manage to get a helicopter to hoist the plane off the beach so it could be salvaged.

…and in case you’re curious where this happened, here’s the location of Carmanah Point Lighthouse:

View Larger Map

Here’s a handy piece of code for finding a style in the ESRI Style Gallery. You simply pass in the style and the category and it returns the appropriate object (if it exists):

 public static object FindEsriWidget(string style, string category)
 {
   try
   {
     // style comparision is case insensitive, without leading/trailing spaces
     string normalizedStyle = style == null ? "" : style.Trim().ToUpper();
     // these are our interfaces and coclasses
     IStyleGallery gallery = new StyleGalleryClass();
     IStyleGalleryItem item = new StyleGalleryItemClass();
     IStyleGalleryStorage storage = (IStyleGalleryStorage)gallery;
     IEnumStyleGalleryItem list = null;
     // get the gallery storage item
     string path = storage.DefaultStylePath + "ESRI.Style";
     // what we're interested in
     list = gallery.get_Items(category == null ? "" : category, path, null);
     // reset our cursor
     list.Reset();
     // enumerate the list as required
     for (item = list.Next(); item != null; item = list.Next())
     {
       // if we find a match, use it
       if (item.Name.Trim().ToUpper().Equals(normalizedStyle))
       {
         return item.Item;
       }
     }
   }
   catch (Exception ex)
   {
      // do something here
   }
   // not found
   return null;
 }

So here a simple way to find a point’s intersect along a polyline. The code includes the ability to include buffer distance. So if the point doesn’t actually intersect, but is within X meters it will also return intersection for the point. Very handy little piece of code. Enjoy.

 public static double GetPointCollectionIntersectIndex(
   IPointCollection points, IPoint point, double? bufferDistanceInMeters)
 {
   object Missing = Type.Missing;
   PointClass queryPoint = new PointClass();
   Polyline testPolyline = new Polyline();
   // first see if point is in collection
   for (int i = 0; i < points.PointCount; i++)
   {
     // get the point in the collection
     points.QueryPoint(i, queryPoint as IPoint);
     // we've found our point along the polyline
     if (queryPoint.Compare(point) == 0) return i;
   }
   // time to do some intersect checks
   for (int i = 1; i < points.PointCount; i++)
   {
     // remove old points if reusing
     if (testPolyline.PointCount > 0) testPolyline.RemovePoints(0, 2);
     // create first point
     points.QueryPoint(i - 1, queryPoint as IPoint);
     testPolyline.AddPoint(queryPoint as IPoint, ref Missing, ref Missing);
     // create second point
     points.QueryPoint(i, queryPoint as IPoint);
     testPolyline.AddPoint(queryPoint as IPoint, ref Missing, ref Missing);
     // get the relation operator for the target geometry and topological operator for buffering
     ITopologicalOperator bufferOperator = testPolyline as ITopologicalOperator;
     // get the row cursor
     IRelationalOperator relationOperator =
       (bufferDistanceInMeters == null ?
         (IGeometry)testPolyline :
         bufferOperator.Buffer((double)bufferDistanceInMeters)) as IRelationalOperator;
     // a disjoint indicates a non-intersection, so if it's false, we have our intersect point
     if (relationOperator.Disjoint(point) == false) return ((double)i) - 0.5;
   }
   // return -1
   return result;
 }
